Vermicomposting requirements
Earthworms can be raised on a broad range of systems: in beds, boxes, pits, cement troughs, and windrows. Their requirements are minimal but important:
Litter
Earthworms need a stable, well-aerated and moist litter (>50% moisture) with a favorable C:N ratio. The litter should not decompose too quickly and should not heat as it can be deleterious to earthworms. The litter can be made of different materials : horse dung, cow dung, pig manure, poutlry litter or peat moss, compost, maize silage, maize stover, chopped bark, wheat straw, oat straw, hay, papers, paper pulp, sludge, cardboard, corrugated cardboard, etc. The litter should be relatively shallow so that earthworms can colonize all their habitat.
Feed sources
Earthworms are voracious and able to consume 50 to 100% of their body weight in one day. They can ingest a broad variety of feeds but they are particularly fond of already degraded organic matter, notably cattle and rabbit dung. Pig manure is readily consumed when dried. Poultry litter is less appreciated due to its high temperature and high protein content, which can be deleterious to earthworms (GEORG, 2004 cited by Munroe, 2008; Gaddie et al., 1975). Other suitable feed include kitchen wastes (when not too rich in nitrogen and fat), precomposted food wastes, sewage biosolids (earthworms are reported to destroy toxic substances), legumes haulms, grains, algae (when thoroughly rinsed to limit salt content), chopped corrugated cardboard etc. Feeds should be distributed regularly and in amounts small enough to prevent fermentation and a rise in temperature that may kill the worms. Quickly composting the wastes before vermicomposting can help to obtain optimal temperature, moisture, ammonia and salt content (El Boushy et al., 2000).
Density and yield
Initial earthworm density should be in the 2.5–5 kg/m² range to ensure an optimal reproduction rate. The earthworm population under favorable conditions may double within 30-60 days. An earthworm facility sown with 10 kg of earthworms can yield 20 kg after 30 days, 40 kg after 60 days and,more than 40 tons in 12-24 months. Yields of 1 kg fresh earthworm per 2 kg calf manure (DM) were reported and it was suggested that a herd of 100 cows producing 3 t manure/day would yield 42 kg earthworm protein/day and 15 t/year (Fosgate et al., 1972).
Vermicomposting systems
Various vermicomposting techniques are used. Most of them consist in making shallow bed layers or windrows of variable width and of limited height (50-90 cm, never more than 1 m) with animal or crop wastes that can range from almost-liquid slurries to straw-based mixtures or relatively dry poultry litter. For efficient vermicomposting, the bed layers moisture and temperature should be monitored and kept to 80-90% moisture and between 15 and 25°C, the latter being reported to be optimal .
Earthworms are seeded after a prior period of composting. As the earthworms are growing, the wastes are added in thin layers of substrate to prevent heating, the overall system should be shaded and constant moisture should be kept by watering and drainage. It requires one month for the vermicompost to get ready. The earthworms can then be harvested (GEORG, 2004 cited by Munroe, 2008; Dominguez et al., 2011; Edwards et al., 2011; Misra et al., 2003; El Boushy et al., 2000).
Here are some examples of vermicomposting systems:
- In the Philippines, earthworms were grown in pits (3 m x 4 m x 1 m depth) drained with bamboo poles to prevent earthworms from being waterlogged. The bed layer was filled with organic residues (straw, crop residues, green weeds, leaves or animal manure) and left for a week to precompost. Earthworms were added and started to burrow. The pits were covered to prevent sunshine and to keep the substrate with adequate moisture. After 2 months, the pits could be partially (66-75%) emptied and the worms were removed by hand or sieving. The yield was 10 kg castings per 1 kg of earthworms. The earthworms were used in new pits, sold for the same purpose sold or as livestock feed, fish feed, or human food (Misra et al., 2003).
- In Cuba, vermicomposting was done in cement troughs. Bed layers were made of 7.5-10 cm layers of one-week old manure. The worms were added and a new layer of manure was added every 10 days to provide new feed. After 2 months, the worms were separated from the compost (Misra et al., 2003).
- In Canada, vermicomposting was done in static outdoor windrows. The litter was made of cardboard and the feeds were poultry and bovine manure. Earthworms were seeded in August and they spent all winter in the windrows under 1 m snow. By next summer the population had been multiplied by 5. The vermicompost was of high quality. Protein rich feeds maintained heat in the windrows during the canadian winters. After harvest, new windrows were set along the old ones so that the earthworms could migrate to the new litter (Munroe, 2008).
- Continuous systems have been developped in Australia. Earthworms are placed in raised containers, about 3 m wide. The feed (biosolids) is sprayed above the worms without disturbing them. The small particles of vermicompost fall through the screen at the bottom of the container. Such systems could process 2-3 t of wastes per day (Bogdanov, 1996).
Earthworm harvest
Eartworms can be harvested using different methods. The many difficulty is that the worms are embedded in the vermicompost, a moist and sticky. The worms must be separated from the castings when they are intended as bait or feed, which can be done manually, by migration, or mechanically (Bogdanov, 1996).
Manual harvesting
Manual harvesting is a time-consuming activity that can be done in smallholder units. The compost is laid on the ground in a relatively thin layer and the earthworms burrow to flee the light. The upper layer is removed repeatedly until the worms can be harvested in the lowest layer where most animals can be found (Misra et al., 2003).
Migration and screening
There are several harvesting methods based on combining migration and screening. Three of them are reported below.
- The vertical top-down migration system can be achieved when vermicomposting has been carried out in continuous vertical systems with a wire mesh bottom. The container is lit from above and earthworms, fleeing the light, are collected at the bottom (Munroe, 2008).
- The vertical bottom-up migration system consists in placing the grid and attractive feed materials (peat moss + coffe pomace or fresh bovine dung) above the earthworm layer. This technique can be done with boxes or with onions bags (bags with wide mesh), as done in Cuba. The earthworms are climbing to the fresh feed and can be collected (Cracas, 2000). One constraint of the technique is that some feed remains with the worms that do not come as clean as they are with other techniques. This can be alleviated by removing most of the excess feed after the harvest (Munroe, 2008)
- The push-pull method developed in India consists in pushing the earthworms out of the vermicompost of coconut leaves with the help of a repellent (mustard) and to subsequently pull them thanks to an attractant (cow dung). The method was found to be effective and able to save manpower (Gopal et al., 2019).
- The horizontal screening technique consists in attracting earthworms to a pre-weighed substrate, such as peat moss, and forcing them through a screen. Once they have passed through the screen, the worm-free compost is removed and another batch of vermicompost replaces it. The operation is repeated until the weight of the receiving substrate reaches the required weight (corresponding to the desired weight of worms + the weight of the substrate at the start) (Munroe, 2008).
Mechanical harvesting
Mechanical harvesting is efficient. It is done with inclined rotary drum screens 2.5-3 m long x 30-60 cm in diameter. The screen is metallic with variable grid size. The drum is electrically powered. The vermicompost is fed by the high extremity of the drum. As the drum rotates, castings pass through the screen and earthworms are collected at the bottom (Bogdanov, 1996).
Preparting earthworms for animal feeding
Washing and blanching
The earthworms should be washed thoroughly and left in water for a duration ranging from 30 min to 8 h, so that they evacuate the residual wastes from their guts. They can later be blanched in boiling water.
Dry feed
Earthworm meal is made by drying (natural or artificial) and then grinding the worms. In smallholders units, earthworms are dried by laying them out in the sun or by using an artificially drying system, sometimes without prior washing or blanching. The ash content of the final meal is directly correlated to the amount of soil contamination. Heating the worms at 120°C for one hour was found to reduce bacterial count and to improve growth in rats (Velazquez et al., 1986). In Nigeria, the earthworms were thoroughly rinsed in water and kept in a bowl for 30 min to let them evacuate residual undigested contents. The worms were then blanched in hot water and oven-dried at 80°C for 3 h. After drying, the worms were milled with hammer milling machine into a powder, packed as dried earthworm meal in airtight plastic bowls and stored at 0-20°C for further use (Sogbesan et al., 2007).
Other drying methods include immersion in acetone (1 hour) followed by air- or oven drying (95°C), and freeze-drying. A comparison of drying methods found that they resulted in slightly different dry matter yields (g of dried product per 100 g of fresh worms):15.2% (hot air), 11.6% (oven), 13.5% (freeze-drying), 12.8% (acetone) (Edwards, 1985).
Wet feed
Earthworms can be ensiled with formic acid or mixed with molasses or with molasses and sorghum (El Boushy et al., 2000; Ortega Cerrilla et al., 1996).
